High frequency transformer manufacturing process of the sixth points: solder

author: MagTop
22/09/2022
High Frequency Tansformer, Low Frequency Tansformer,Toroidal Tranformer
Company News | common mode chokes | Industry News | transformer|RJ45 connectors

1) After soldering, PIN foot is smooth and free from foreign matter.
2) The thread end should not be higher than the convex point.
3) After soldering, BOBBIN is complete, no damage and short foot phenomenon.
4) Welding oil (flux) residual less, no tin, no short circuit.
5) The adhesive tape has no damage tolerance.
6) Solder at least a full circle.
7) There can be no transverse tin tip after soldering
