High frequency transformer manufacturing process points of seven: Combination

author: MagTop
SMD power transformer,High Frequency Tansformer, Low Frequency Tansformer,Toroidal Tranformer
Company News | common mode chokes | Industry News | transformer|RJ45 connectors
1) The combination surface of the iron core is flat and without skew.
2) BOBBIN, CORE and wiring pins should be kept clean and free from impurities and glue.
3) Identify where CORE with GAP is located.

4) The maximum skew of EE, EI and UU CORE shall not be greater than 0.5mm or 1/10core width
